Open Type Disabled Platform Lifts

Disabled Elevators

Open Type Disabled Platform Lifts

MK-901

Open Type Wheelchair Platform, Open Disabled Platform, Open Type Disabled Lift

User and environmental safety is kept at the highest level.

This model structured on double pillars. It has high safety standards and stylish. It can be used safely inside and outside. The outer cover is made of stainless steel. Does not required pit and can travels up to 3 meters elevation differences.

Areas of usage; School, Temples, Police station, Rehabilitation center, Public institutions, Hotels, Health facilities, Training centers, Housing estates.

MK 901 model is manufactured within the standards of 2006/42 / EC and is presented to the market with CE marking. User and environment safety are in highest level.

Open Type Disabled Platform Lifts

Technıcal Spesıfıcatıons

Technicial Specifications

Kabin Yükseklik

1000 m

Installation

Installation in 1-2 Days

Power Suply

220 - 380 v (AC)

Speed

0,15 m/s

Guarantee

2 years

Floor Number

Drive System

Hydraulic - screwed

Travel Height

3 m

Sizes

Dimensions

Drive Type	Hydraulic / Screw
Carrying Capacity	315 kg
Maximum Travel Distance	3 mt
Working Speed	0,15mt/sec
Platform Internal Dimensions	900*1400 mm / (Special Dimension)
Platform External Dimensions	1400*1400 mm / (Special Dimension)
Pit	100 mm
Door	Automatic Locking-Safety Switch (Optional)
Controls	Locked Controls On Floors And Platform Emergency Stop Button
Safety	Anti Jamming Switches Under The Table / Bellows (Optional)
Main power requirement	220 V AC - 50 Hz - Single Phase

Colors

Profile Color Options

RAL 9005

RAL 9016

RAL 7012

RAL 7016

RAL 7032

RAL 7035

Colors

Glass Color Options

Transparent Glass

Blue

Fume

Bronze

Profile Properties

RAL Paint

Stainles Steel

Door Features

Circleslide Automatic Door

Manuel Door

Download Product Brochure

Download the product brochure with detailed information and technical data.

Download Brochure

Get Offer

We provide services in the manufacturing and installation of open type wheelchair platforms, disabled platforms, open wheelchair platforms, open wheelchair lifts, open disabled lifts, and open type wheelchair platform lifts. You can get information on prices for open wheelchair platforms, disabled lifts, and wheelchair platform prices.
